The SUNDRAY Gigabit H Series Network Controller is independently researched and developed by SUNDRAY, it has excellent performance, and integrates many features in one platform, adopting ONE-IS-ALL design, such as wireless controller, switch management center, user authentication, portal server, access control, report center, marketing push, consumer big data analysis, VPN, smart network topology, WIPS, east-west traffic security, basic firewall, etc.
Based on SDN structure, the controllers can manage all SUNDRAY industry AP and V-Sec Switch, and support the deployment in any L2 or L3 network, which can reduce the complexity of the network configuration and maintenance, suitable for the network update in the chain supermarket, school, hotel, hospital, government, bank and scenic spot, etc.
Specification:
Product Model
NAC-220H
Port number
5*Gigabit Ethernet port 1* RJ 45 Console port 1* RJ 45 Manage port 2* USB 2.0 ports 1*expansion slot
Power Consumption
<31w
Operating Temperature, Storage Humidity
Operating Temperature：0℃～40℃/-40℃～70℃
Storage Humidity：5% ~ 95% (non-condensation)
Weight / Dimensions (L*W*H) mm
4 kg / 430*300*44.5
Power Input
Optional dual power supply
Input voltage: Rated voltage range: 110V～240V AC；50/60Hz
Hard disk
128G SSD
Maxonline Concurrent Users
8000
